Rigid polyurethane foam sandwiched between metal or flexible facings, manufactured from 25mm to 200mm to the highest international standards — a cost-effective system for buildings and energy conservation.
Explore Sandwich PUF Panels
Overview
Aquaproof roofing sheets are available as insulated panels, with rigid polyurethane foam sandwiched between two metal sheets. Panels run from 30mm to 75mm thick and give a cost-effective route to excellent thermal insulation in steel buildings, for energy conservation.
No screw penetrates the sheet.
Clamps fix without penetration.
Insulation cuts the cooling load.
Specifications
Composite panels are produced with internal and external sheets of aluminium, steel or other architectural materials in different thickness, coating and colour.
THICKNESS
30–75mm
Insulated Aquaproof panels
PROFILE
6-Rib Aquaproof
Self-locking caps at the ribs
CORE
Rigid PU Foam
Between two metal sheets
INSUROOF TILE
1065mm
Nominal width, 195mm tile pitch
Gallery
FAQ
Panels are manufactured from 25mm to 200mm, with the polyurethane itself available from 15mm. Thickness follows the U-value you need: at 35 kg/m³ density, 25mm gives 0.96 W/m²°C, 35mm gives 0.68 and 50mm gives 0.48. Higher density is available on request.
Ready when you are
Tell us your span, temperature range and finish — we'll specify and quote the right panel.
