Rock Wool Sandwich Panels.
Prime rock wool sandwich panels for roof and wall, supplied in up to 1 m effective width and single lengths up to 12 m without joints, depending on site requirements.
On this page
Specification
Specified to the micron.
Roof panel thickness
50 – 100 mm
50 mm, 80 mm and 100 mm roof panels.
Wall panel thickness
100 & 120 mm
Lloydroc HR 1 and HR profiles.
Single length
Up to 12 m
In up to 1 m effective width, without joints.
| Property | Roof panel | Wall panel |
|---|---|---|
| Top sheet profile | Prime profiled sheet | Plain sheet with slight ribbed profile |
| Bottom sheet profile | Plain sheet with slight ribs | HR profile |
| Panel thickness | 50 mm – 80 mm & 100 mm | 120 mm & 100 mm |
| Facing material | 240 MPa GI with 180 GSM zinc coating / 300 MPa galvalume steel with 150 GSM Alu-Zn coating | 240 MPa GI with 180 GSM zinc coating / stainless steel / 300 MPa galvalume with 150 GSM Alu-Zn |
| Facing material thickness | 0.4 / 0.5 / 0.6 / 0.7 mm TCT | 0.4 / 0.5 / 0.6 / 0.7 mm TCT |
| Coating DFT | 20 microns colour coated RMP / SMP / PVDF over 5 micron primer | 20 microns colour coated RMP / SMP / PVDF over 5 micron primer |
Fixing — roof
Fastened to purlin and girt.
Panels are fixed on the purlin or girt with hot-dipped galvanized imported self-drilling fasteners with EPDM washers, with the necessary overlap as per manufacturer's specification.
Fixing — wall
Tongue and groove into channels.
Wall panels have a tongue and groove joint and are fixed on channels on the floor and onto a suitable structure with flashings.
Fire
DIN 4102Mineral core fire properties.
Fire resistance, ignitability, surface spread of flame and combustibility are all assessed to DIN 4102 for the rock wool core.
Ready when you are
Specify a rock wool panel.
Tell us the fire rating and span you need and we will confirm the panel thickness, facing grade and fixing detail.
